VCPSRBD0600N18R10 CARBIDE ENDMILL
Corner Radius End Mill; 6 mm Dia. × 6 mm LOC × 6 mm Shank Dia. × 70 mm OAL ; AlTiN ; Series VCPSRB
| Cutting Diameter (DC) | 6 mm | Usable Length (LU) | 18 mm |
| Connection Diameter Machine Side (DCONMS) | 6 mm | Corner Radius (RE) | 1 mm |
| Depth of Cut Maximum (APMX) | 6 mm | Neck Diameter (DN) | 5.85 mm |
| Overall Length (OAL) | 70 mm | Peripheral Effective Cutting Edge Count (ZEFP) | 4 |
| Coating | AlTiN | Length Group | Short |
| Flute Helix Angle (FHA) | 30 Degrees | Measurement Type | Metric |
| End Shape | Corner Radius | Series/List # | VCPSRB |
Product Features
| Country of Origin | Japan |
Shipping Info
Additional Fees and Notes
0
Package Weight
0.4
